描述
| Enclosure Type | Sealed |
| Enclosure Finish | Black Gloss |
| Frequency Response (Anechoic) | 22 - 118 Hz (±1.5dB) -3 dB at 21 Hz / 120 Hz -10 dB at 17 Hz / 153 Hz |
| Effective Piston Area (Sd) | 84.4 sq in / 0.0545 sq m |
| Effective Displacement | 235 cu in / 3.9 L |
| Amplifier Power | 1500 W RMS short-term |
| Power Mode(s) | Off, On or Automatic (Signal-Sensing) |
| Light Modes | N/A |
Signal Processing
| Unbalanced Inputs | Stereo or Mono (two RCA jacks) |
| Balanced Inputs | N/A |
| Speaker/High-Level Inputs | Stereo or Mono (removeable plug) |
| Input Grounding | Isolated or Grounded |
| Input Modes | N/A |
| Level Control | Variable, from full mute to +15dB over reference gain |
| Filter Mode(s) | Low-Pass |
| Filter Slope(s) | 24 dB/octave |
| Filter Frequency Range | 25 Hz - 130 Hz |
| Filter Defeat Function | Yes |
| Polarity | 0 or 180 degrees |
| Phase | Variable, 0- 280 degrees, referenced to 80 Hz |
| Extreme Low Frequency (E.L.F.) Trim | N/A |
| Line Outputs | Stereo or Mono (two RCA jacks), High-Pass or Pass-Through |
| Output to Slave | N/A |
| Calibration Mode | N/A |
Physical Specifications
| Width (W) | 15.5 in / 394 mm |
| Height (H) | 16.23 in / 412 mm |
| Depth (D) | 18.39 in / 467 mm |
| Net Weight | 73.5 lb / 33.3 kg |
| Note: Height dimensions include feet. | |
