描述
重要特點：
-
可自由定義功能用途的20聲道前級輸出
-
具備Dolby Atmos、DTS:X與Auro-3D解碼能力
-
以高精度4點式咪高峰測量各聲道喇叭
-
數位音源信號採取64 bit浮點運算處理
-
以Trinnov Optimizer優化頻響、相位與暫態響應特性
-
專利的Remapping處理、能解決喇叭擺位的問題
- 8 X HDMI 2.0 Input / 2 X HDMI 2.0 Output
3D AUDIO CODECS UPMIXERS & DECODERS
16 CHANNELS APPLICATIONS
- DISCRETE 9.1.6 IMMERSIVE SOUND
- DISCRETE 7.3.6 IMMERSIVE SOUND
- DISCRETE 9.3.4 IMMERSIVE SOUND
- 7.2.4 WITH SCREEN BI-AMP
- 5.1.4 WITH SCREEN BI-AMP
- 7.2 FULL BI-AMP AND A LOT MORE!
INCLUDED IMMERSIVE AUDIO DECODERS
- DOLBY ATMOS®
- AURO-3D®
- DTS:X®
- FUTURE 3D DECODERS SOFTWARE UPGRADE INCLUDED
AUDIO PROCESSING
- ADC Resolution / Sampling Rate: 24 bits/96 kHz
- DAC Resolution / Sampling Rate: 24 bits/96 kHz
- A/D Signal-To-Noise Ratio: 119 dB (A-Weighted)
- D/A Signal-To-Noise Ratio: 118 dB (A-Weighted)
- Analog Input Impedance: 20 k Ohms / 10 k Ohms
- Reference Level: +18dBu @ 0dBFS (Balanced)
- Clock / Jitter: attenuation > 50 dB above 100Hz)
- Power Supply: Independent for audio and processing
- Safety Components: AntiPop relays on each output
ANALOG INPUTS
ANALOG OUTPUTS
- 1 XLR 5 points microphone input
- 1 stereo balanced input on XLR
- 1 stereo single ended input on RCA
- 16 balanced XLR outputs.
DIGITAL INPUTS
DIGITAL OUTPUTS
NETWORK AUDIO
- 4 S/PDIF inputs (using 2 optical/coax)
- 2 S/PDIF outputs (using 2 optical/coax)
- Dual audio network Ethernet connector
HDMI BOARD
- 2 Outputs ( HDMI 2.0/ HDCP 2.2)
- 8 Inputs (all ins configurable to HDMI 2.0/ HDCP2.2)
- Maximum Resolution 4K UHD on all-ins/out
- Maximum Bandwidth 18Gbps on all inputs
- Frame rate 24/25/30/50/60
TRIGGER
- 4 outputs trigger including 1 fixed and 3 programmable ones
- 1 input trigger (not programmable)
ROON READY
- Trinnov Altitude is fully compatible with Roon
PHYSICAL CHARACTERISTICS
- Data precision: 64 bits, floating point
- RAM: 2Gb
- Storage: Flash drive
- Cooling system: Custom heat sinks + additional silent fans
- Size / Dimensions 438mm x 430mm x 138.40mm
- Weight: 11.30Kg
