BENQ W5700i 4K HDR color accurate director camera, 100% DCI-P3 standard color gamut

• W5700 won the Visual GrandPrix Award, the highest honor in Japan's audio and video evaluation, and is known as the "Oscar in the audio and video field". In the past, only Japanese brands could win this honor.



• It uses 11 elements/6 groups of aspherical all-glass lenses, specially coated low-dispersion glass lenses, and a large F/1.8 aperture to minimize chromatic aberration or color fringes, bringing unparalleled 4K UHD sharpness and saturation.


• 100% DCI-P3 color gamut, 4K UHD high resolution, supports 4K HDR / Bluray 3D high-definition video



• 100-inch projection at 3 meters, 1.6x large zoom projection range, large two-way lens shift, increasing installation convenience

• Exclusive HDR-PRO™ technology optimized for projectors, supporting HDR10/HLG high dynamic range effects

Specifications

• Resolution: 4K UHD (3840 x 2160)
• Brightness (ANSI Lumens): 1800 ANSI Lumens
• Contrast Ratio (FOFO): 100,000:1 (w/ Dynamic Iris)
• Projection System: DLP
• Contrast Ratio (FOFO): 100,000:1 (Dynamic Iris)

• Display Color: 30 Bits (1,07 billion colors)
• Native Aspect Ratio: Native 16:9 (3 aspect ratio selectable)

• Light Source: Lamp
• Light Source Life: Normal 4,000 hours, Economic 10,000 hours, SmartEco® 8,000 hours


Optical

• Throw Ratio: 1.36 ~ 2.18 (100" @ 3 m)

• Zoom Ratio: 1.6x
• Lens: F/# 1.81~2.1, f 14.3(Wide) ~ 22.9(Tele)

• Lens Shift: ± 60% / Horizontal: ± 23%

• Keystone Adjustment: 1D, Vertical ± 40 degrees

• Image Size: 60" ~ 200" / 300" (Clear Focus / Maximum)


• Picture Mode: ISF Disabled: Bright / Vivid / Cinema (Rec. 709) / D. Cinema / Silence / 3D / User 1 / HDR / HLG, ISF Enabled: Bright / Vivid / Cinema (Rec. 709) / D. Cinema/ Silence/ISF Night/ISF Day

• Color Wheel Segment: 6-Segment (RGBRGB)‎
• Color Wheel Speed: 2D: 96Hz; 100Hz; 120Hz - 3D: 100Hz, 120Hz

• Rec.709 Coverage: 100%
• DCI-P3 Coverage: 100%

Interface

• HDMI: x2 HDMI (2.0b/HDCP 2.2)
• USB Type A: x1 (5V/2.5A power), x1 (Media Reader, FW download), x1 (USB 3.0 Media Reader/ Firmware upgrade)

• USB Type mini B: x1 Firmware upgrade

• Audio out (3.5mm Mini Jack): x1
• LAN (RJ45): x1 RJ-45 LAN input jack (10/100M)
• RS232 (DB-9pin): x1 RS232 In (D-sub 9pin, male)
• DC 12V Trigger (3.5mm Jack): x1 (3.5mm Jack)
• IR Receiver: x2 (Front/Top)
• Wired Remote in (3.5mm Mini Jack): x1

Special Feature

• HDR: Yes (HDR10, HLG)
• Motion Enhancer (MEMC): Yes
• ISF Night/Day: Yes
• LAN control: Yes
• CinemaMaster Video +: Yes (4K Motion Enhancer, 4K Pixel Enhancer, Color Enhancer, Flesh Tone)

Compatibility

• HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p


Power

• Power Supply: VAC 100 ~ 240 (50/60Hz)
• Typical Power Consumption: Max 405W, Normal 330W, Eco 247W

• Standby Power Consumption: 0.5W Max. at 100 ~ 240VAC
• Network Stand-by Power Consumption: <2W
• Acoustic Noise (Typ./Eco.): 32dBA / 26dBA

Dimension and Weight

• Dimensions (W x H x D)(mm): 492 x 168 x 3493
• Net Weight (Kg/ lbs): 6.5kg
