Description
DALI SUB E-12 F Active Subwoofer
- All DALI Speakers sold by our company are genuine products.
- This product comes with a 1-year warranty and free delivery service (Hong Kong only).
The DALI SUB E-12 F is an active subwoofer featuring a 12″ all-aluminum diaphragm driver. It boasts exceptionally balanced and outstanding low-frequency reproduction capabilities, making it suitable for two-channel or multi-channel systems. Its compact size allows for easy placement in any space, complementing DALI's OPTICON MK2, FAZON, OBERON, and SPEKTOR speaker series. The 12″ all-aluminum diaphragm driver minimizes distortion; it is robust, lightweight, and offers excellent transient response, perfectly matching the main channels. Its cone design eliminates the need for a dust cover, ensuring precise piston movement.
The SUB E-12 F's built-in Class D amplifier delivers 170W with high linearity, perfectly matching the demands of its drivers. Designed for continuous high-power output, it reaches a peak of 220W, satisfying the needs of many demanding movie or music playback applications. The cabinet, meticulously designed by DALI's R&D team, utilizes robust MDF and is available in Black Ash and White. For vibration damping, it features four oversized feet approximately 30mm high. The all-aluminum alloy base is not only sturdy but also aesthetically pleasing.
DALI SUB E-12 F Subwoofer
● Single unit: 12″ all-aluminum diaphragm, long stroke
● Frequency response: 28-190Hz (+-3dB)
● Frequency crossover adjustment: 40-120Hz
● Continuous power output: 170W (RMS)
● Maximum power output: 220W (RMS)
● Maximum sound pressure level: 112 dB
● Input Interfaces: RCA, stereo (low-pass filtered), LFE (mono)
● Input impedance: 25K ohms
● Maximum power consumption: 250W
● Dimensions: 3370 x 340 x 380mm
● Weight: 14.7Kg
DALI SUB E-12 F SPECS
| Product Series | SUBWOOFERS |
|---|---|
| Frequency Range (+/-3 dB) [Hz] | 28 - 190 |
| Maximum SPL [dB] | 112 |
| Crossover Frequency [Hz] | 40 - 120 |
| Low frequency driver, Quantity | 1 x 12" long stroke |
| Low frequency driver, Diaphragm type | Polymere Aluminum |
| Enclosure type | Bass Reflex |
| Bass Reflex Tuning Frequency [Hz] | 36.0 |
| Max. Amplifier Power Output [RMS watt] | 220 |
| Continuous IEC Power Output [RMS watt] | 170 |
| Input Impedance [ohms] | 25k |
| Connection Input | Mono Line Level (LFE) RCA Stereo Line Level (low pass filtered) |
| Magnetic Shielding | No |
| Recommended Placement | Floor |
| Recommended Distance From Wall [cm] | > 5 |
| Functions | Crossover Frequency Phase Switch Standby (Auto Power) On/Off Switch Volume (Gain) |
| Max. Power Consumption [W] | 250 |
| Dimensions With Base (HxWxD) [mm] | 370 x 340 x 380 |
| Accessories Included | Manual Rubber Bumpers Spikes M6 |
| Weight [kg] | 14.7 |
